Stainless Steel Quarter Turn 5mm Double Bit Lock for Electrical Enclosures

SKU
£13.90 ex. VAT £16.68 inc. VAT
In stock
21 in stock across 1 warehouse
Free Shipping

Ask an expert!

Chat Email 01527 433383
  • Material Stainless Steel 316
  • IP Rating IP66

Stainless Steel Quarter Turn 5mm Double Bit Lock for Electrical Enclosures

FEATURES

– Specially designed internal spring provides 1.5 mm of compression.

MATERIAL

HOUSING: Stainless Steel
DRIVER: Stainless Steel
GASKET: Rubber
IP RATING: IP66

DRIVERS

IP-L026: 5mm Square

DIMENSIONS

H=25.5mm

CL=49mm

Standards & certifications

IP66Dust-tight · powerful jets
